RT-6016Q-G2

RT-6016Q-G2 POS terminal is the pole-mounting version of the RT Series from Posiflex. Unlike the standard desktop RT Series terminal that requires optional module for PoweredUSB functionality, RT-6016Q-G2 comes with a built-in 24V PoweredUSB port by default. users can enjoy the convenience that the PoweredUSB port offers while the terminal is being pole-mounted or wall-mounted. The RT-6016Q-G2 features an internal cable organizer that makes clean cable routing even easier.

Slim & Stylish Look

With sleek contours, an ultra-slim body, and a linear rear cover surface, the RT-6016Q-G2 features a 15" PCAP touch display and a full suite of ports hidden within the clean rear cover. No screws can be seen on the cover surface, maintaining a neat and sleek aesthetic.

Clean Cable Management

With 24V PoweredUSB, which provides power to peripherals without the need for additional power adapters, it offers a cleaner cable management solution.

Save Your Time and Money

RT-6016Q-G2 can be shipped with a 9.7” 2nd LCD display or a line display attached, saving deployment time and cost.

Fan-free Technology

The fan-free technology allows the RT-6016Q-G2 to run quietly in all kinds of harsh conditions while also providing a long service life.

Faster Installation and Serviceability

Rear cover can be removed easily and without tools, thus allowing faster installation and serviceability.

RT-6016Q-G2 Specification

Processor Intel Tiger Lake Core i3-1115G4E, up to 3.90 GHz, 6M Cache
Intel Tiger Lake Core i5-1145G7E, up to 4.10 GHz, 8M Cache
Intel Tiger Lake Core i7-1185G7E, up to 4.40 GHz, 12M Cache
OS Support Windows 10 IoT 64 bits
System Memory DDR4 SO-DIMM slot x 2, max. 32GB
Storage Device 2 x M.2 connector [Support both SATA and PCIe signal]
RAID Function Yes
Intel vPro Support Yes, with Core i5 & i7
TPM Support Yes, TPM 2.0
Power Supply 12V/150W

Display & Touch

LCD 15.6" TFT LCD
Resolution 1920 X 1080
Touch True-flat PCAP touch with multi-touch support (IP65 on front panel)

I/O Expansion

Serial Port 3, DB9 x 1 + RJ50 x 2,  5V/12V support on all COM ports
Parallel Port N/A
Standard USB Por 5, USB 3.0 x 2 + USB 2.0 x 3
PoweredUSB Port 24V PoweredUSB x 1
OTG USB N/A
LAN Port 10/100/1000 Mb x 1
Display Port VGA via proprietary connector (12V support for Posiflex monitors) x 1+ mini DP x1
CR Port 1, control 2 CR via optional Y-cable, supporting 24V cash drawer
PS/2 Port N/A
UPS Port N/A
Audio Internal 2W speaker x 1
Expansion Slot M.2 2230 x 1 for Wi-Fi/BT

Physical Dimension

Dimension (W x D x H in mm) 402 x 207 x 297
Weight (N. W. in g) 5

Environmental

Operation Condition 0°C - 40°C, 20%RH - 90%RH
Storage Condition -20°C - 70°C, 10%RH - 90%RH

Built-in Options

WIFI M.2 WiFi/BT module
Camera 1MP wide angle camera
MSR N/A
AG Glass Cannot coexist with built-in camera

Attachment Options

POS Monitor Non-touch TFT LCD: 9.7"/10.1"/15";
PCAP touch TFT LCD: 9.7"/10.1"
Line Display 2 x 20 rear-mount VFD customer line display
External UPS Pack For RT Series N/A
Attachment MSR; 2D Scanner; RFID; Fingerprint Sensor
